651030-1 Carbide Tipped Dado 10 Inch Dia x 24T ATB/FT 10 Deg, 1 Inch Bore, Dado Set

More Views

651030-1 Carbide Tipped Dado 10 Inch Dia x 24T ATB/FT 10 Deg, 1 Inch Bore, Dado Set

Be the first to review this product

Availability: In stock

$399.95

Details

Dadoes (cross-grain cuts) and grooves (cuts with the grain) are cut efficiently on the table saw with a dado stack set. Unlike a wobbler, a stack set produces a flat-bottom cut with chip-free edges. Amana Tool® makes dado stack sets for every machine and every type of woodworking material. The standard width capacity ranges from 1/8" to 13/16". Additional chippers may be purchased separately to expand the capacity beyond 13/16". The standard set, regardless of diameter or tooth count, consists of two outside saw blades and four inside chippers. The outside blades feature hollow-ground plates for proper clearance, and alternate top bevel (ATB) grind with every sixth tooth flat ground (FT).

For plywood and melamine, the sets with 46-tooth outside blades are recommended.

Teeth refers to the number of teeth for each outside saw blade.

Specification
(D) Diameter 10 (250mm)
Teeth 24
(d) Bore 1
Tooth Grind ATB/FT
Hook Angle 15°
ATB Angle 35°
Kerf (B) 1/8 - 13/16

Additional

SKU 651030-1
Weight, lb 1.0000
Dimensions No
Country of Manufacture United States
Manufacturer Amana Tool
