Plunge Round Over Insert CNC Router Bits
This bit creates a flat-bottom groove between two quarter-round shapes. Short vertical walls extending below the radius lend extra depth to the appearance. Depending upon the cut depth adjustment the radii can be flush with the work surface or recessed. The profile can be formed on an edge using an edge guide or on the router table a fence.
Maximum RPM 14 000.
These tools have an open flute design (not anti-kickback) and are intended for high feed-rate CNC machine use only.
Do not use in portable routers.
| (D) Diameter | 2 |
|---|---|
| (R) Radius | 3/4 |
| (B) Cutting Height | 1-7/16 |
| (d) Shank | 1/2 |
| Overall Length (L) | 2-15/16 |
| B1 | 1-1/8 |
| Flutes | 2 |
| D1 | 1/2 |
Additional
| SKU | 49710-CNC |
|---|---|
| Weight, lb | 1.0000 |
| Dimensions | No |
| Country of Manufacture | United States |
| Manufacturer | Amana Tool |
